ecovacs-part3:UI and script.

ecovacs-part3  UI

create a script

If you only want to clean a specific room, create a script like this:

sequence:
  - action: select.select_option
    metadata: {}
    data:
      option: mop
    target:
      entity_id: select.your-vacuum-id_work_mode_2
    alias: Select 'Select' on your-vacuum-id 工作模式 - mop
  - action: number.set_value
    metadata: {}
    data:
      value: "0"
    target:
      entity_id: number.your-vacuum-id_volume_2
    alias: Number 'Set' on your-vacuum-id 音量 - 0
  - action: vacuum.send_command
    metadata: {}
    data:
      command: clean_V2
      params:
        act: start
        content:
          type: freeClean
          value: 1,9
    target:
      entity_id: vacuum.your-vacuum-id_2
    alias: Vacuum 'Send command' on  - start
mode: single
alias: " Script - Vacuum mop bookroom - only mop"
description: >-
  https://blog.matterxiaomi.com/blog/ecovacs-part3/
  https://community.home-assistant.io/t/how-to-create-a-script-or-action-to-clean-specific-room-ecovacs-x2/780893/14?u=msly



UI

For the dashboard, you can create buttons for each room to press like this:

views:
  - title: Home
    header:
      card:
        type: markdown
        text_only: true
        content: |-
          # Hello {{ user }}
          Add your text here, template variables are supported ✨
    sections:
      - type: grid
        cards:
          - type: heading
            heading: New section
          - type: horizontal-stack
            cards:
              - show_name: true
                show_icon: true
                type: button
                entity: script.new_script_mop_bookroom
                icon: mdi:toilet
                name: WC









Useful links

UI and script

https://community.home-assistant.io/t/how-to-create-a-script-or-action-to-clean-specific-room-ecovacs-x2/780893/14
